ELECTRIC

EMD10 SE

Engine: 2000W48V neodymium magnet BRUSHLESS motor
Battery: 48V23AH lithium battery
Charger: 54.6V/5.0A
Transmission: Chain drive, speed adjustable
Final Drive : 9T/65T, 35# KMC chain
Tires:Front 2.75-14", rear 3.00-12"
Brake system: Front & rear disc brake
Suspension: Hydraulic, front inverted fork & rear mono shock
Range per full charge: 60km
Max.speed: 65km/h
Max load capacity: 80kgs
Wheelbase: 1080mm
Seat height: 710mm
Min ground clerance: 250mm
Dry weight: 51kgs
Packing carton size:
QTY/Container:

EMD10 PRO
Engine: 2500W48V neodymium magnet BRUSHLESS motor
Battery: 60V27AH lithium battery
Charger: 67.2V/5.0A
Transmission: Chain drive, speed adjustable
Final Drive : 9T/65T, 35# KMC chain
Tires:Front 2.75-14", rear 3.00-12"
Brake system: Front & rear disc brake
Suspension: Hydraulic, front inverted fork & rear mono shock
Range per full charge: 60km
Max.speed: 70km/h
Max load capacity: 80kgs
Wheelbase: 1110mm
Seat height: 730mm
Min ground clerance: 230mm
Dry weight: 51kgs
Packing carton size:
QTY/Container:

EMD12 19/16

Engine: 3000W72V neodymium magnet brushless motor
Peak power: 8000W
Battery: 72V35AH lithium battery
Optional : 72V40AH lithium battery
Charger: 84V/6A
Transmission: Chain drive, 3 drive mode
Final Drive : 14T/51T, 420# chain
Tires:Front 70/100-19", rear 90/100-16"
Brake system: Front & rear disc brake
Suspension: Hydraulic, front inverted fork & rear mono shock
Range per full charge / 35 AH: ~70km
Range per full charge / 40 AH: ~78km
Max.speed: 88kmph
Max load capacity: 90kgs
Wheelbase: 1240mm
Seat height: 860mm
Min ground clerance: 335mm
Dry weight : 74kgs/35AH ; 76kgs/40AH
Packing carton size: 1560*380*850mm
QTY/Container: 132pcs/40HQ
