Page 2 -

ELECTRIC

EMD09

Engine: 800W/1000W 36V BRUSH motor
Battery: 36V7.8AH lithium battery
Optional : 36V10.4AH lithium battery
Charger: 42.0V/1.5A
Transmission: Chain drive, speed adjustable
Final Drive : 9T/80T, 25H# chain
Tires:Front 16x2.40, rear 2.50-10"
Brake system: Front & rear disc brake
Suspension: Hydraulic, front fork & rear mono shock
Range per full charge: 25km
Max.speed: 28km/h
Max load capacity: 65kgs
Wheelbase: 930mm
Seat height: 630mm
Min ground clerance: 250mm
Dry weight: 35kgs
Packing carton size: 1060*380*545mm
QTY/Container: 300pcs/40HQ

EMD07 14/12
Engine: 1300W48V neodymium magnet BRUSHLESS motor
Optiontal: 1800W48V neodymium magnet BRUSHLESS motor
Battery: 48V15.6AH lithium battery
Charger: 54.6V/2.0A
Transmission: Chain drive, speed adjustable
Final Drive : 10T/76T, 219H# chain
Tires:Front 2.75-14", rear 3.00-12"
Brake system: Front & rear disc brake
Suspension: Hydraulic, front inverted fork & rear mono shock
Range per full charge: 40km
Max.speed/1300W: 42km/h
Max.speed/1800W: 52km/h
Max load capacity: 65kgs
Wheelbase: 1010mm
Seat height: 680mm
Min ground clerance: 250mm
Dry weight: 40.5kgs
Packing carton size: 1290*370*660mm
QTY/Container: 280pcs/40HQ

EMD12 17/14

Engine: 3000W72V neodymium magnet brushless motor
Peak power: 6500W
Battery: 72V30AH lithium battery Optional : 72V35AH lithium battery
Charger: 84V/6A
Transmission: Chain drive, 3 optional drive mode
Final Drive : 14T/51T, 420# chain
Tires:Front 70/100-17", rear 90/100-14"
Brake system: Front & rear disc brake
Suspension: Hydraulic, front inverted fork & rear mono shock
Range per full charge / 30 AH: ~60km
Range per full charge / 35 AH: ~70km
Max.speed: 80kmph
Max load capacity: 90kgs
Wheelbase: 1200mm
Seat height: 825mm
Min ground clerance: 290mm
Dry weight : 70kgs / 30AH ; 72kgs / 35AH
Packing carton size: 1560*380*850mm
QTY/Container: 1 32pcs/40HQ
