GASOLINE
SA110 UA501
Engine: 110cc,1 cylinder- 4 stroke, air cooled Engine: 110cc,1 cylinder- 4 stroke, air cooled
Optional: 125cc,1 cylinder- 4 stroke, air cooled Transmission: Chain drive, auto clutch with reverse gear
Transmission: Chain drive, auto clutch with reverse gear Final drive: 14T/37T, 420# chain
Final drive: 14T/37T, 420# chain Starting system: Electric start only
Starting system: Electric start only Fuel tank volume: 2.0L
Fuel tank volume: 2.0L Battery: 12V5AH
Battery: 12V5AH Tires: Front & rear 16x8-7''
Tires: Front & rear 16x8-7'' Optional: Front 19x7-8'' and rear 18x9.5-8''
Optional: Front 19x7-8'' and rear 18x9.5-8'' Brake system: Front drum brake, rear disc brake
Brake system: Front drum brake, rear disc brake Suspension: A swing arm with double shock,rear mono shock
Suspension: A swing arm with double shock , rear mono shock Max.speed: 55kmph
Max.speed: 55kmph Max load capacity: 90kgs
Max load capacity: 90kgs Wheelbase: 960mm
Wheelbase: 960mm Seat height: 620mm
Seat height: 670mm Min ground clerance: 130mm
Min ground clerance: 130mm Dry weight: 105kgs Dry weight: 110kgs
Packing carton size: 1310*760*640mm QTY/Container: 36pcs/20FT, 106pcs/40HQ Packing carton size: 1250*760*640mm QTY/Container: 39pcs/20FT, 108pcs/40HQ
UA505
Engine: 110cc,1 cylinder- 4 stroke, air cooled
Transmission: Chain drive, auto clutch with reverse gear
Final drive: 13T/37T, 420# chain
Starting system: Electric start only
Fuel tank volume: 1.6L
Battery: 12V5AH
Tires: Front & rear 16x8-7''
Optional: Front 15x5.00-6'' and rear 15x6.00-6''
Brake system: Front & rear disc brake
Suspension: A swing arm with double shock , rear mono shock
Max.speed: 50kmph
Max load capacity: 65kgs
Wheelbase: 815mm
Seat height: 570mm
Min ground clerance: 95mm
Dry weight: 75.5kgs
Packing carton size:
QTY/Container:
UA125
Engine: 110cc,1 cylinder-4 stroke, air cooled
Optional: 125cc,1 cylinder-4 stroke, air cooled
Transmission: Chain drive,auto clutch with reverse gear
Final Drive: 14T/37T, 420# chain
Starting system : Electric start only
Fuel tank volume: 2.0L
Battery: 12V5AH
Tires: Front &rear 16x8-7"
Optional: Front 19x7-8" and rear 18x9.5-8"
Brake system: Front drum brake and rear disc brake
Suspension: A swing arm with double shock, rear mono shock
Max. speed: 55kmph Max load capacity: 90kgs
Wheelbase: 985mm
Seat height 7"/8" wheels: 660mm / 675mm
Min ground clerance 7"/8" wheels: 200mm / 215mm
Dry weight 7"&8" wheels: 93 kgs / 110kgs
Packing carton size: 1360*770*645mm
QTY/Container: 36pcs/20ft , 100pcs/40HQ
